3dprinting

A collection of 27 posts

Micro Breadboard Mount for USB Power Supply

Micro Breadboard Mount for USB Power Supply

Loosely inspired by the Apple Cube USB Charger Bracket [http://www.thingiverse.com/thing:1290842], this is a mount for a 5V A1 USB power supply (this one at Adafruit [https://www.adafruit.com/products/501] and a tiny breadboard [https://www.adafruit.com/products/65]. There is a small

USB Helper Enclosure

USB Helper Enclosure

This is a commissioned work for fellow Tindie seller Black Brix [https://www.tindie.com/stores/Dirk/]'s USB Helper / USB Switch [https://www.tindie.com/products/Dirk/usb-helper--usb-switch-kit/]. The product was sent to me to produce an enclosure for safety and aesthetics. [ imgur.com [http://imgur.com/a/

Particle Electron Breadboard Box

Particle Electron Breadboard Box

This is a derivative of my original Breadboard Project Box with a few key modifications: * Removed battery holding area * Added side "channels" to hold cellular antenna * Corner channels for battery wires 3D model and more available at [ thingiverse.com [http://www.thingiverse.com/thing:1385961] ]. Also available for

Control Everything Sensor Enclosures

Control Everything Sensor Enclosures

Simple sensor enclosures for a majority of the Control Everything I2C sensors [https://www.controleverything.com/products?f[0]=field_assigned_categories%3A6172] . It probably won't fit for the gas and pressure sensors or sensors with terminals on the edges of the PCBs. More variations may be added

Control Everything Photon Relay Enclosure

Control Everything Photon Relay Enclosure

This is a simple enclosure for Relay Shield for Particle Photon I²C 2-Channel SPDT 10-Amp 6 Programmable Digital Input Output [https://www.controleverything.com/content/Relay-Controller?sku=MCP23008_SCIO6R2G5LE_10A] . The top is held in place by small tabs. 3D model and more available at [ thingiverse.com [http://www.

Raspberry Pi Stacking Tower

Raspberry Pi Stacking Tower

This is a minimal yet relatively secure way to stack your Raspberry Pi's vertically. This is a universal B design in that it works with the original B, the 2 B, and presumably the B+ (I don't have a B+). The design goals were something that

Nixie Tube Clock Frame

Nixie Tube Clock Frame

I recently received and assembled a Nixie Clock Kit (not my kit) for my birthday. However, there's a 180V no-touch area. With 2 kids, I wanted to build in a little extra safety to keep fingers from wandering into the danger zone. It also helps to block out

Pole Plug Helper

Pole Plug Helper

I usually don't like to publish one-off prints like this, but it was so handy that I can't help it! My garage door opener plugs into an outlet in the ceiling of my garage. I don't have a 6+ foot ladder to reach the

Internet Button Mount

Internet Button Mount

The Particle Internet Button is a fun little device on a horizontal, flat surface. However, I wanted to mount mine to a wall. The "bubble" is loose, so it wouldn't stay on in a vertical situation. This aims to resolve that issue. It also allows the

3dprinter-statsd

3dprinter-statsd

A small Node.JS script to periodically grab temperature metrics from a 3D printer (via OctoPrint) and send them to a StatsD instance. Source code and instructions available at [ github.com [https://github.com/wgbartley/3dprinter-statsd] ].

Frame / Enclosure for 16x32 RGB Matrix Clock

Frame / Enclosure for 16x32 RGB Matrix Clock

A friend designed a shield for a Particle Photon to connect to a 16x32 RGB matrix panel. This is a backing frame to hide the electronics and add stability to the panel with an enclosure over the shield. Featured on Adafruit's #3DThursday blog! [https://blog.adafruit.com/2015/

Breadboard Project Box

Breadboard Project Box

Just a simple box to hold a half-length breadboard and small components. There are two compartments for batteries (1x AA, 1x AAA), and one big compartment for holding small components or a booster circuit like a joule thief. 3D model available at [ thingiverse.com [http://www.thingiverse.com/thing:930427]

Message Torch Bottle Base

Message Torch Bottle Base

This is a rather specific base for a message torch. It's designed to fit an Ocean Vodka bottle with a Spark Core / Particle Photon beneath. It's a two-piece print and the top should fit snugly into the bottom. 3D model available at [ thingiverse.com [http://www.

7-Segment Clock

7-Segment Clock

A rather large 7-segment, 4-digit clock powered by a Particle Photon. Synchronizes time with the Internet (using built-in wireless), display local (as in a sensor inside the clock itself) temperature/humidity, and display current outdoor temperature and humidity. There are a couple of different display modes (solid color, chasing rainbow)

Enclosure for Micro-Lipo USB Charger

Enclosure for Micro-Lipo USB Charger

An enclosure for an Adafruit Micro Lipo - USB LiIon/LiPoly charger - v1 [https://www.adafruit.com/products/1304]. 3D model available at [ thingiverse.com [http://www.thingiverse.com/thing:649154] ]. Also available for purchase in my Tindie store at [ tindie.com [https://www.tindie.com/products/wgb/enclosure-for-micro-usb-charger/

Rail Hook Coat Hanger

Rail Hook Coat Hanger

My friends have a split foyer home with a railing on the main level right next to the door. For whatever reason, I felt like it would make a nice place to hang coats when we visit. The railing is 1" (25.4mm) square, so the internal sides are

Numbered Bases for Minis - 25mm

Numbered Bases for Minis - 25mm

These are numbered bases (1 through 10 and 11 through 20) for table top gaming minis with 25mm / 1" round bases. They come in very handy for DMs when managing a roomful of kobolds. Any more than that, and your DM is being a jerk. Model available at [ thingiverse.

Numbered Bases for Minis - 49mm

Numbered Bases for Minis - 49mm

These are numbered bases (1 through 4) for table top gaming minis with 29mm / 2" round bases. They come in very handy for DMs when managing a roomful of trolls. Any more than that, and your DM is being a jerk. Model available at [ thingiverse.com [http://www.thingiverse.

TARDIS Battery Base for Joule Thief

TARDIS Battery Base for Joule Thief

Light up your TARDIS off of a single AA or AAA battery! This design runs off of a joule thief to light up your LEDs off of a single 1.5v battery. It can even run off of "dead" batteries that don't have enough juice to

FlatMinis: Male Druid

FlatMinis: Male Druid

A more masculine version of the existing FlatMinis Female Druid. Model available at [ thingiverse.com [http://www.thingiverse.com/thing:620311] ].

FlatMinis: Halfling Thief

FlatMinis: Halfling Thief

This is a combination remix of the dwarf and thief flat minis. Model available at [ thingiverse.com [http://www.thingiverse.com/thing:620294] ].

Shelf Extender Brackets

Shelf Extender Brackets

We had some spare pegs and scrap wood to add another much-needed shelf in one of our kitchen cabinets. Unfortunately, the depth of the wood I had came up a few inches shy. After a few minutes of design and a couple hours of printing, I saved myself a few

Enclosure for Mini-Lipo USB Charger

Enclosure for Mini-Lipo USB Charger

An enclosure for an Adafruit Mini Lipo w/Mini-B USB Jack - USB LiIon/LiPoly charger - v1 [https://www.adafruit.com/products/1905]. Featured on Adafruit's #3DThursday blog! [https://blog.adafruit.com/2014/10/23/printed-enclosure-for-adafruit-mini-lipo-usb-charger-for-wearables-projects-by-wgbartley-3dthursday-3dprinting/] 3D model available at [ thingiverse.com [http://www.thingiverse.com/thing:

Fold-up Laundry Hanger

Fold-up Laundry Hanger

My wife saw something like this in a magazine and asked if I could put my new hobby to use for making something functional! It allows you to hang up to 5 hangers on the wall. Arm will swivel up to get it out of the way when not in

Yet Another Loose Filament Spooler

Yet Another Loose Filament Spooler

Because the one thing Thingiverse needs is another loose filament spooler. I tried a few and liked bits and pieces of each one, but wanted to combine their features into one that works well for me! Model available at [ thingiverse.com [http://www.thingiverse.com/thing:440592] ].
