Photon IoT Gateway

Photon IoT Gateway

Not all IoT devices are part of the Particle Cloud. Now they can be! Read more at [ hackster.io [https://www.hackster.io/wgbartley/photon-iot-gateway-85dcca] ].

particle-statsd

particle-statsd

A small Node.JS script to monitor a Particle pubsub event stream and send metrics to a StatsD instance. Source code and instructions at [ github.com [https://github.com/wgbartley/particle-statsd] ].

statsd-graphite

statsd-graphite

A Docker container running a combined StatsD + Graphite + Carbon stack for super quick metrics collection and display. Docker image available at [ hub.docker.com [https://hub.docker.com/r/wgbartley/statsd-graphite/] ].

3dprinter-statsd

3dprinter-statsd

A small Node.JS script to periodically grab temperature metrics from a 3D printer (via OctoPrint) and send them to a StatsD instance. Source code and instructions available at [ github.com [https://github.com/wgbartley/3dprinter-statsd] ].

Word Clock v2

An improvement over v1 with lessons learned. Read more at [ hackster.io [https://www.hackster.io/wgbartley/word-clock-v2-26adee] ]. Source code available at [ github.com [https://github.com/wgbartley/word-clock-v3] ].

Frame / Enclosure for 16x32 RGB Matrix Clock

Frame / Enclosure for 16x32 RGB Matrix Clock

A friend designed a shield for a Particle Photon to connect to a 16x32 RGB matrix panel. This is a backing frame to hide the electronics and add stability to the panel with an enclosure over the shield. Featured on Adafruit's #3DThursday blog! [https://blog.adafruit.com/2015/

Breadboard Project Box

Breadboard Project Box

Just a simple box to hold a half-length breadboard and small components. There are two compartments for batteries (1x AA, 1x AAA), and one big compartment for holding small components or a booster circuit like a joule thief. 3D model available at [ thingiverse.com [http://www.thingiverse.com/thing:930427]

Message Torch Bottle Base

Message Torch Bottle Base

This is a rather specific base for a message torch. It's designed to fit an Ocean Vodka bottle with a Spark Core / Particle Photon beneath. It's a two-piece print and the top should fit snugly into the bottom. 3D model available at [ thingiverse.com [http://www.

Word Clock v1

Wi-fi enabled word clock. 130 characters with 130 NeoPixels! Project build at [ hackster.io [https://www.hackster.io/wgbartley/word-clock-v1-c880a7] ]. Source code available at [ github.com [https://github.com/wgbartley/word-clock-v3] ].

7-Segment Clock

7-Segment Clock

A rather large 7-segment, 4-digit clock powered by a Particle Photon. Synchronizes time with the Internet (using built-in wireless), display local (as in a sensor inside the clock itself) temperature/humidity, and display current outdoor temperature and humidity. There are a couple of different display modes (solid color, chasing rainbow)

Enclosure for Micro-Lipo USB Charger

Enclosure for Micro-Lipo USB Charger

An enclosure for an Adafruit Micro Lipo - USB LiIon/LiPoly charger - v1 [https://www.adafruit.com/products/1304]. 3D model available at [ thingiverse.com [http://www.thingiverse.com/thing:649154] ]. Also available for purchase in my Tindie store at [ tindie.com [https://www.tindie.com/products/wgb/enclosure-for-micro-usb-charger/

Rail Hook Coat Hanger

Rail Hook Coat Hanger

My friends have a split foyer home with a railing on the main level right next to the door. For whatever reason, I felt like it would make a nice place to hang coats when we visit. The railing is 1" (25.4mm) square, so the internal sides are

Numbered Bases for Minis - 25mm

Numbered Bases for Minis - 25mm

These are numbered bases (1 through 10 and 11 through 20) for table top gaming minis with 25mm / 1" round bases. They come in very handy for DMs when managing a roomful of kobolds. Any more than that, and your DM is being a jerk. Model available at [ thingiverse.

Numbered Bases for Minis - 49mm

Numbered Bases for Minis - 49mm

These are numbered bases (1 through 4) for table top gaming minis with 29mm / 2" round bases. They come in very handy for DMs when managing a roomful of trolls. Any more than that, and your DM is being a jerk. Model available at [ thingiverse.com [http://www.thingiverse.

TARDIS Battery Base for Joule Thief

TARDIS Battery Base for Joule Thief

Light up your TARDIS off of a single AA or AAA battery! This design runs off of a joule thief to light up your LEDs off of a single 1.5v battery. It can even run off of "dead" batteries that don't have enough juice to

FlatMinis: Male Druid

FlatMinis: Male Druid

A more masculine version of the existing FlatMinis Female Druid. Model available at [ thingiverse.com [http://www.thingiverse.com/thing:620311] ].

FlatMinis: Halfling Thief

FlatMinis: Halfling Thief

This is a combination remix of the dwarf and thief flat minis. Model available at [ thingiverse.com [http://www.thingiverse.com/thing:620294] ].

Shelf Extender Brackets

Shelf Extender Brackets

We had some spare pegs and scrap wood to add another much-needed shelf in one of our kitchen cabinets. Unfortunately, the depth of the wood I had came up a few inches shy. After a few minutes of design and a couple hours of printing, I saved myself a few

Enclosure for Mini-Lipo USB Charger

Enclosure for Mini-Lipo USB Charger

An enclosure for an Adafruit Mini Lipo w/Mini-B USB Jack - USB LiIon/LiPoly charger - v1 [https://www.adafruit.com/products/1905]. Featured on Adafruit's #3DThursday blog! [https://blog.adafruit.com/2014/10/23/printed-enclosure-for-adafruit-mini-lipo-usb-charger-for-wearables-projects-by-wgbartley-3dthursday-3dprinting/] 3D model available at [ thingiverse.com [http://www.thingiverse.com/thing:

Fold-up Laundry Hanger

Fold-up Laundry Hanger

My wife saw something like this in a magazine and asked if I could put my new hobby to use for making something functional! It allows you to hang up to 5 hangers on the wall. Arm will swivel up to get it out of the way when not in

Yet Another Loose Filament Spooler

Yet Another Loose Filament Spooler

Because the one thing Thingiverse needs is another loose filament spooler. I tried a few and liked bits and pieces of each one, but wanted to combine their features into one that works well for me! Model available at [ thingiverse.com [http://www.thingiverse.com/thing:440592] ].

Extruder Plate 5mm LED Mount

Extruder Plate 5mm LED Mount

Just a simple piece that allows you to add a single 5mm LED to your extruder. Attaches to the hot end mount plate. Model available at [ thingiverse.com [http://www.thingiverse.com/thing:440552] ].

Particle Micro Breadboard Enclosure

Particle Micro Breadboard Enclosure

A small enclosure for a 170-point micro breadboard (2.2" x 2.1" x 1.5"). The holes are sized specifically for a Spark Core microcontroller and optional antenna. There is a small riser in the holder to allow room for antenna and/or hookup wires to

Light-Up Dress

21 LEDs across 3 circuits controlled by an (underclocked) Adafruit Gemma that can run for days on a small LiPo battery! Source code available at [ github.com [https://github.com/wgbartley/awe-chloe-dress] ]. For the dress, contact my wife at [ facebook.com [https://www.facebook.com/birchavenueapparel] ], [ storenvy.com [http://www.

Outdoor Lighting Relay Control

Outdoor Lighting Relay Control

I have a SainSmart 4-Channel Relay Module that I've been using with 4 rocker switches and a 5v cell phone charger to turn the relays on and off. It controls some deck lights, patio lights, and umbrella lights, plus one extra outlet for whatever else (usually big box
